Amorphous Alloy Ribbon
Amorphous Alloy Ribbon

Amorphous alloy, also known as "liquid metal or metallic glass", is a new type of soft magnetic alloy material, mainly containing iron, silicon, boron and other elements. The manufacturing process of its main products, amorphous alloy thin ribbon, is to use the rapid cooling technology. The alloy molten liquid is cooled at 106℃ per second, forming a thickness of about 0.03mm amorphous alloy thin ribbon, leaving the physical state a disordered amorphous arrangement of metal atoms. Thanks to the special atomic structure formed by the above extreme production process, the amorphous alloy has excellent properties such as low coercivity, high permeability, high resistivity, high temperature corrosion resistance and high toughness.

Technical Specifications

type of ribbon

saturation flux density(T)

densityρ

(g/cm3)

the Curie temperature(℃)

crystallization temperature

specific resistance

μΩ*cm

magnetostriction coefficient(*10-6

Vickers hardness

(50gload)

AYFA-A

1.56

7.20

404

524

137

27

877

AYFA-M

1.60

7.25

394

516

114

27

841

AYFA-N

1.62

7.27

385

469

125

30

810

Physical Specifications


type of ribbon

thickness

(μm)

width

(mm)

width allowance(mm)

mm

Coefficient of laminated(%)

(mm)

Unit of iron lossPs1.3/50(w/kg)

excitation power

Ss1.3/50(VA/kg)

AYFA-A

25±2

100-240

±0.5

≥88

≤0.085

≤0.13

AYFA-M

≤0.085

≤0.13

AYFA-N


≤0.085

≤0.13

Typical Applications
  • 1.Reactors for inverters, transformer cores ;
  • 2.Wide constant inductance core, PFC inductance core
  • 3.Amorphous electromagnetic shielding foil for digital electronics
